MODEL |
RMGE 001 |
RMGE FE 002 |
Rolls Width x Diameter |
127 x 63.5 (5"x2.5") |
145 x 70 (5.75"x2.75") |
Operation System |
Motorized |
Motorized |
Wire Grooves From - To |
0.75 - 9 |
0.75 - 9.5 |
Max. Sheet Width |
48 |
54 |
Wires in Fully Grooved Rolls (Optional) |
0.75 - 10 |
0.75 - 10.5 |
Max. Apertures Of Rolls |
25 |
25 |
No. of Half Round Grooves |
2 |
2 |
Max. Roller Speed |
6.88 (M/Min.) |
7.57 (M/Min.) |
Depth per rotation of staring |
0.50 |
0.50 |
Power Supply |
1 HP/0.75Kw. 1Phase |
1 HP/1.75Kw. 1Phase |
Machine Dimension (C.M) |
61 x 30 x 82 |
65 x 30 x 82 |
Machine Net. Weight |
118.70 Kg. |
129.00 Kg. |
Shipping Dimension (C.M) |
75 x 47 x 85 |
75 x 47 x 85 |
Shipping Weight |
160 Kg. |
175 Kg. |
ALL ABOVE DAIMANTION ARE IN M.M.
