MODEL |
RMFD 001 |
Rolls Width x Diameter |
101 x 57 (4"x2.25") |
Operation System |
Motorized |
Wire Grooves From - To |
0.75 - 7 |
Max. Sheet Width |
37 |
Wires in Fully Grooved Rolls (Optional) |
0.75 - 8 |
Max. Apertures Of Rolls |
6 |
No. of Half Round Grooves |
2 |
Max. Roller Speed |
7.57 (M/Min.) |
Depth per rotation of staring |
0.78 |
Power Supply |
1 HP/0.75Kw. 1Phase |
Machine Dimension (C.M) |
38 x 48 x 117 |
Machine Net. Weight |
148 Kg. |
Shipping Dimension (C.M) |
65 x 54 x 132 |
Shipping Weight |
220 Kg. |
ALL ABOVE DAIMANTION ARE IN M.M.
