MODEL
LDH 01
LDH 002
Rolls Width x Diameter
101 x 57 (4"x2.25")
127 x 63.5 (5"x2.5")
Wire Grooves From - To
0.75 - 8
0.75 - 9
Max. Sheet Width can be Rolled
60
80
Max. Apertures Of Rolls
20
18
No. of Half Round Grooves
2
2
Max. Roller Speed
7.57 (M/Min.)
7.57 (M/Min.)
Depth per rotation of staring
0.78
0.75
Power Supply
1 HP/0.75Kw. 1Phase
1.5 HP/1.1Kw. 1Phase
Machine Dimension (C.M)
60 x 31 x 117
80 x 35 x 115
Machine Net. Weight
161 Kg.
213 Kg.
Shipping Dimension (C.M)
75 x 50 x 132
95 x 51 x 130
Shipping Weight
220 Kg.
300 Kg.

ALL ABOVE DAIMANTION ARE IN M.M.

Due to continuous innovation & improvements, Specification is subject to change without notice.
