MODEL |
RMDH 01 |
Rolls Width x Diameter |
89 x 51 (3.5"x2") |
Wire Grooves From - To |
0.75 - 5.75 |
Max. Sheet Width Rolled |
36 |
Max. Apertures Of Rolls |
6 |
No. of Half Round Grooves |
2 |
Max. Roller Speed |
3.85 (M./Min.) |
Depth per rotation of staring |
0.81 |
Power Supply |
0.75 HP / 0.56 Kw. - 1 Phase |
Machine Dimension (C.M) |
58 x 27 x 87 |
Machine Net. Weight |
114 Kg. |
Shipping Dimension (C.M) |
78 x 47 x 107 |
Shipping Weight |
150 Kg. |
ALL ABOVE DAIMANTION ARE IN M.M.
