MODEL |
RMSH 003 |
RMSH 004 |
RMSH 004+ |
RMSH 005 |
RMSH 006 |
Rolls Width x Diameter |
152 x 76 (6"x3") |
152 x 101 (6"x4") |
203 x 101 (8"x4") |
200 x 125 (8"x5") |
250 x 150 (10"x6") |
Wire Grooves From -To |
As per Requirement |
As per Requirement |
As per Requirement |
As per Requirement |
As per Requirement |
Max. Sheet Width Can Be Rolled |
75 |
100 |
125 |
150 |
200 |
Max. Apertures Of Rolls |
38 |
38 |
38 |
38 |
42 |
Max. Roller Speed |
11.66 (M/min.) |
13.00 (M/min.) |
13.00 (M/min.) |
16.00 (M/min.) |
23.00 (M/min.) |
Depth per Rotation of Staring |
0.99 |
0.99 |
0.99 |
0.99 |
0.99 |
Power Supply |
2 HP / 1.5 Kw. |
5 HP / 3.75 Kw. |
5 HP / 3.75 Kw. |
7.5 HP / 5.62 Kw. |
10 HP / 7.5 Kw. |
Machine Dimension in cm. |
77 x 38 x 138 |
88 x 70 x 180 |
120 x 51 x 160 |
120 x 51 x 165 |
160 x 60 x 170 |
Machine Approx Weight |
285 Kg. |
375 Kg. |
500 Kg. |
700 Kg. |
900 Kg. |
ALL ABOVE DAIMANTION ARE IN M.M.
Due to continuous innovation & improvements, Specification is subject to change without notice.
RMDH 004 & 005 ARE AVAILABLE WITH ROUND STARING WHEEL.
eXTRA ATTACHMENT AVAILABLE : FULL WIRE GROOVE ROLLS, FEEDING GUIDE, COIL WINDING UNIT, AC DRIVE REGULATED RPM PANEL.
